CAM350 reduces these complex shapes into simple outlines with circular or polygonal voids. Certain CAD systems generate so-called cutline polygons that are used for efficient flooding and display. The File > Import > Gerber Data command has been updated for CAM350 V10.1 to include faster polygon processing. Gerber Import and Export Improvements – The File > Import > Gerber Data command has been updated for CAM350 V10.2 to report illegal self intersecting polygons and prompt the user with the option to repair. 9 Gerber Import and Export Improvements.The following functional enhancements are contained in CAM350 Version 10.1 CAM350 10.1 also delivers over 50 important customer reported defect resolutions.ĬAM350 Version 10.0 introduced significant new functionality, including reading and writing BluePrintPCB files, new graphics user interface, a project explorer bar, flip panel support, design compare, Expedition cross probing, and various enhancements.
Optimization for memory usage is delivered in CAM350 10.1 for all polygon analysis, which means that larger more complex layers of polygons can now be processed for commands such as Netlist Extract and Gerber Import.
Areas of improved performance include Gerber import and ODB++ import. CAM350 10.1 includes performance improvements and memory usage improvements over previous releases of CAM350. Other CAM350 updates include resolutions for customer reported problems concerning ODB++ support for offset pads and flip panels, mill tabs in route arcs and mill route support for flipped images.ĬAM350 10.2 includes Gerber import improvements for polygon self intersection analysis and DRC analysis accuracy updates for polygon outlines with arcs.ĬAM350 Version 10.1 is a support release for CAM350. CAM350 10.2.2 includes support for Microsoft Windows 7 and Mentor PADS Layout version 9.2. The OrCAD Lite version will let you experience all the features and functionality of the actual software limited only by the size and complexity of the design.CAM350 Version 10.2.2 is a support release for CAM350. Compare OrCAD PSpice Designer and OrCAD PSpice Designer Plus to determine which best fits your design needs. OrCAD PSpice technologies come in different product configurations that offer specific levels of functionality to fit your budget constraints, design flows, and simulation requirements. OrCAD PSpice Designer OrCAD PSpice Designer Plus
